Solo 461 - Cordless Heat Detector Tester Kit

The SOLO461 Heat Detector Tester operates with abattery to direct heated air at heat detector sensors. Ituses a patented CAT™ (Cross Air Technology) systemto focus the air and direct it horizontally at the sensor regardless of the detector's size or shape.

Cross Air Technology Under control of a microprocessor, blown air is heated by the element just before exiting the duct. The narrow opening focuses the heated air into a beam. A reference platform incorporated into the Heat Detector Tester ensures that the beam of heated air is correctly lined up with the sensor whatever the shape and size of the detector. Because the beam of hot air is blown horizontally directly at the sensor:

  • Battery powered – no hanging wires / tangled cables
  • Lightweight and simple to use
  • Suits fixed temperature, rate-of-rise and combination detectors up to 194°F / 90°C
  • Unique IR activation & Cross Air Technology for optimum energy use and results
  • Universal design suits widest range of detectors
  • Adjustment lever for angled surfaces
  • Transparent test cup for clear view of detector LED
  • Includes 2 Slim NiMH battery batons and charger for rapid charging

• Test times are dramatically reduced

• Minimum power is required thereby extending battery life

• The possibility of heat damage to detector plastics is significantly reduced

Tool Operation When the tool is fully assembled, press the switch on the tester to put the tool into standby mode. When the tester is positioned so that it encloses a detector, the detector interrupts an infrared beam turning on the heater and blower units in the tester. Hold the tool in place over the detector until either:

• the detector alarms indicating proper operation

• until the tool automatically times out indicating a problem with the detector When the tool is moved away from the detector or when the tool times out the heater shuts off and the blower runs for a few seconds to cool the heater.

Region Certification Europe CE Solo 461 USA UL URRQ.S4994, URRQ.S7201 SOLO461

Quant.             Component

1                         SOLO461 Heat Detector Tester

2                         SOLO720 Battery

1                         Charging set with mains and car connector

1                         Literature pack

Technical specifications
Electrical
Charging set operating voltage
• Alternating voltage 110 to 240 V AC ~50/60 Hz
• Direct voltage 11 to 16 V DC
Mechanical Weight
• Without battery 600 g (21 oz)
• With battery 1.1 kg (38.8 oz)
Dimension (Ø x H) 99.5 mm x 52 mm (3.9 in x 2 in)
Environmental
Operating temperature 5 °C to 45 °C (40 °F to 115 °F)
Storage temperature -10 °C to 50 °C (15 °F to 120 °F)
Permissible relative humidity 85% (non-condensing)
Trademarks

SOLO461 Heat Detector Tester
Heat Detector Tester operating with a battery Order number SOLO461

SOLO610 Test Equipment
Bag Robust bag made of sturdy woven polyester for carrying and storing test and service products. Order number SOLO610

SOLO100 Telescopic Access Pole
Enables the installation and replacement of fire detectors at high ceilings. Expandable with up to three SOLO101 Fixed Extension Poles. A SOLO100 is supplied in America, while a SOLO106 is supplied elsewhere. Order number SOLO100

SOLO101 Fixed Extension Pole
Enables the installation and replacement of fire detectors at ceilings. Expandable with other Fixed Extension Poles. Order number SOLO101

SOLO720 Battery
Rechargeable battery bar for the SOLO461 Heat Detector Tester Order number SOLO720

* Operating status display with multi-color LED
* Automatic detector recognition with infrared sensors
* Automatic switch-off after 5 min. standby time u Automatic switch-off in case of battery overvoltage
* Enters standby mode after 120 seconds of use


Electrical Specification
Voltage Range Alternative Voltage 110 to 240 V AC ~50/60 Hz DC Voltage 11 to 16 V DC
Operation Temperature 5 °C to 45 °C (40 °F to 115 °F) Storage:-10 °C to 50 °C (15 °F to 120 °F) 0-85% RH humidity
Batarey Capacity 3000mAh / 7.2V NiMh
Functions Cross Air Technology Microprocesser Controller Cordless Optional Access Pole Battery Auto On/off
Technical
Application Heat Detector Tester Test kit
Made In England
Certificates UL URRQ.S4994, URRQ.S7201 SOLO461 CE
Dimensions
Dimension 99.5 mm x 52 mm (3.9 in x 2 in)
Weight withouth Battery 0,6kg With Battery 1.1 kg
